BBT 2" Submersible/Bore Water Pump – 2200W - 21,000L/H- 63M Head

BBT Submersible/Bore Water Pump – 2200W - 21,000L/H - 63M Head

High-Flow, High-Capacity Pumping Solution for Deep Wells

Delivering powerful water transfer and exceptional lift capacity, the BBT 4" Submersible Bore Water Pump is designed for demanding applications in deep wells, agricultural irrigation, and large-scale water supply. Equipped with a heavy-duty control box, this pump ensures reliable performance and motor protection under intense operating conditions.

Key Features:

Heavy-Duty Construction for Lasting Durability

• Stainless steel motor casing and pump body offer superior corrosion resistance.

• Robust internal components withstand continuous operation and harsh environments.

High-Performance Water Transfer

• Power: 2200W motor designed for efficient, high-capacity pumping.

• Maximum Flow Rate: 21,000 L/h – capable of rapid water transfer for demanding applications.

• Maximum Head: 63m – ideal for deep well pumping and elevated delivery.

• Max Immersion Depth: 150m – suitable for deep boreholes and large reservoirs.

Reliable Control Box Integration

• Control box provides secure operation and safeguards motor performance.

• Thermal and overload protection extend pump service life.

• Smooth start-up and operational stability in varying conditions.

Versatile Applications:

• Deep well and borehole water extraction

• Agricultural irrigation and livestock watering

• Residential water supply systems

• Industrial water transfer

• Large-scale water storage filling

Specifications:

• Model: 4XRm16/10-2.2

• Power: 2200W (240V, 50Hz)

• Maximum Flow Rate: 21,000 L/h

• Maximum Head: 63m

• Max Immersion Depth: 150m

• Outlet Size: 2"

• Inlet Size: 4"

• Cable Included: No

• Control Box Included: Yes

Powerful. Efficient. Reliable.
Designed for intensive water transfer tasks, the BBT 4" Submersible Bore Water Pump delivers unmatched performance and robust construction for deep well and remote pumping applications.

BOX 1: 1650mm X 100mm X 120mm 27.3KG

BOX 2: 240mm X 170 X 100mm 1KG
